Hyd-Mech V-18 - Mechanical Assemblies; Blade Brush Assembly

Pg 6.1 V18 2001c
SECTION 6, MECHANICAL ASSEMBLIES
BLADE BRUSH ASSEMBLY
ITEM QTY S-22 PART NUMBER DESCRIPTION
1 1 S22-43-01B SHAFT EXTENSION
2 1 W6440-4 BEARING
3 1 S20-925-03 POLYURETHANE WHEEL
4 1 5043 3" BLADE BRUSH
5 2 .5FLT FLAT WASHER
6 1 .5-13HXNUT HEX NUT
7 1 S1-.25X.25-C SOCKET SET SCREW, CUP POINT
8 2 TC 13 COMPRESSION SPRING
9 4 .375FLT FLAT WASHER
10 2 A1-.375X3.5 SOCKET HEAD CAP SCREW
11 1 S1-.375X2.5 SOCKET SET SCREW, FLAT POINT
12 1 .375-16HXNUT HEX NUT
13 1 S22-431-00A BEARING PLATE WELDMENT
