4.4
TB3
A close up view of TB3 is shown.
Page 1 shows the position of TB3 in the control panel.
For example, if the electrical schematic shows a terminal, described as TB3
7
This indicates that the terminal is located on din rail TB3 and is terminal #7.
TB3
16 This would indicate that the terminal is mounted on TB3 and is terminal #16.
TB4
TB4 is located in another control panel and will be included on page 7.
TB3
7
TB3
16
To Next Page
