4.7
TB4
TB4 is located in the HMI panel (Human Machine Interface). This houses the selector switches and push buttons.
As in the main panel the same concept applies, for example: TB4
25
This indicates that the terminal is located on din rail TB4 and is terminal #25.
TB4
25
