4.6
TB6
TB6 Contains ground terminals (partially visible) mounted either side of the contactors MS1M & MS2M and are indicated
on the schematic as TB6 & TB6
1 2
The mounting location in the control panel is shown on page 1
TB6
1
TB6
2
