E7 2. Transmitting relay same options as with E5, sta-
tus 14 = factory setting
Parameter Setting / Data
Parameters
010
E8 3. Transmitting relay same options as with E5, sta-
tus 13 = factory setting
Parameter Setting / Data
Parameters
010
E9 4. Transmitting relay same options as with E5, sta-
tus 16 = factory setting
Parameter Setting / Data
Parameters
010
E17 Baud rate (interface) 9600 / 4800 / 2400 / 1200 Parameter Setting / Data
Parameters
010
G0 Calibration °C actual
value
-5 to 5 K Parameter Settings/
Steam Bath Parameters
010
G1 Hysteresis controller 0 - 10 K
1 K = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G2 Steam Bath °C set Value 0 - 49 °C
45 °C = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G3 Hysteresis exhaust fan 0 - 10 K
1 K = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G4 Time essence injection 0 - 25 sec.
2 sec. = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G5 Interval time essence
injection
0 - 99 min.
5 min. = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G6 Hysteresis essence
injection
0 -25 K
25 K = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G7 Hysteresis °C max. 0 -25 K
10 K = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G8 Fan run-on time 0 - 999 min.
0 min. = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G9 Power retention 0 - 100 %
0 % = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
G13 Hysteresis supply fan 0 - 10 K
1 K = Factory Setting
Parameter Settings/
Steam Bath Parameters
010
H1 Counter Partial Blow-
down
0 - 255 [Filling Cycle] Parameter Setting/Blow-
Down Parameters
010
H2 Time Partial Blow-down) 0-255 [s] Parameter Setting/Blow-
Down Parameters
010
H6 Full Blow-Down Yes (On)
No (Off)
Parameter Setting/Blow-
Down Parameters
010
H11 CounterPartial Blow-
down
0 - 999 kg Parameter Setting/Blow-
Down Parameters
010
H12 TimePartial Blow-down 0-255 [s] Parameter Setting/Blow-
Down Parameters
010
P1 Output limitation 25% - 100% Parameter Setting/
Conrol Parameters
none
P2 Maintenance interval 0,1 - 25,5 [10³ kg] Parameter Setting/Mainte-
nance Parameters
010
P3 Reset maintenance
interval
Yes / No Parameter Setting/Mainte-
nance Parameters
010
P5 Address 1 - 999 Parameter Setting/ Data
Parameters
none
P11 Reset main contactor
interval
Yes / No Parameter Settings/Main-
tenance Parameters
010
Para-
meter
Designation Possible Settings in Menu / Submenu Access
Code
