Page 85
14. Terminal Assignments on the Unit Con-
nector Strip and Wiring Diagram Legend
Unit Connector Strip:
Terminals Assignment
1 / 2 Remote Switch / Safety Interlock
6 / 7 Temperature Sensor
8 / 9 / 13 Essence Injector max. 70 W / 24 V / 3,15 A
10 / 11 Exhaust Fan max. 40 W / 24 V / 1,6 A
10 / 12 Supply Fan max. 40 W / 24 V / 1,6 A
14 / 15 Light max. 40 W / 24 V / 1,6 A
17 / 18 / 19 Essence Injector max. 70 W / 230 V / 300 mA
20 / 21 Exhaust Fan max. 40 W / 230 V / 175 mA
20 / 22 Supply Fan max. 40 W / 230 V / 175 mA
44 / 45 Light 40 W / 230 V / 175 mA
Wiring Diagram Legend:
Designation Specification
B1 Max.-Water Level Electrode
B3 Transducer
F1 Fuse Control 1,6 A
F2 Fuse Transformer 5 A
F3 Essence Injector Fuse 2,5 A
F4 Exhaust Fan Fuse 1,6 A
F5 Supply Fan Fuse 1,6 A
F6 Light Fuse 1,6 A
K1 Main Contactor
L1 - L3 Main Terminals
M1 Blow-Down Pump
N Neutral
PE Grounding Terminal
S1 Control Switch ON (I) / OFF (0), pumping (II)
X1 Connector Strip
Y1 Solenoid Valve
Y2 SUPER FLUSH (optional)
