6. Parameters
6.1 Summary Table of Parameters
Para-
meter
Designation Possible Settings in Menu / Submenu Access
Code
A4 Standby Blow-down 0 Min. - 999 Hours[ HHH : MM
]
Parameter Setting/Blow-
Down Parameters
none
A17 Stand-By heating No/Yes Start-up/System settings 010
C16 Interval time A17 0 - 999 min. Settings/Power Parame-
ter
010
C17 On time A17 0 - 255 sec. Settings/Power Parame-
ter
010
D0 Steam bath mode “with status” / “without status” Parameter Setting/Steam
Bath Parameters
010
D1 Exhaust fan Exhaust Fan Automatic / Con-
tinuous Operation
Parameter Setting/Steam
Bath Parameters
010
D2 Essence (injection) Essence Injection Automatic /
off
Parameter Setting/Steam
Bath Parameters
010
D3 Light Light on/off Parameter Setting/Steam
Bath Parameters
010
D4 Supply fan Supply Fan Automatic / Con-
tinuous Operation
Parameter Setting/Steam
Bath Parameters
010
D5 limitation of operating
time
0 - 255 h(0 is Factory setting
(=off))
Parameter Setting/Steam
Bath Parameters
010
E1* Xp-PI-controller=100/
E1[Amplification]
0 - 100 % Parameter SettingsControl
Parameters
010
E2* Tn-PI-controller[Integra-
tion time]
0 - 255 sec. Parameter SettingsControl
Parameters
E5 Base relay
(programmed switching
signal)
0= collective fault (Factory
Setting)
1= Fault Data Exchange
2= Humidification
3= Stand-By
4= Max. Level
5= Blow-Down Fault
6= Maintenance Interval
Expired
7= Fault Filling
8= No Demand
9= ----
10= ----
11= Activated Thermo Sensor
12= Fault Main Contactor
13= Supply Fan
14= Exhaust Fan
15= Essence Injection
16= Light
17= Super Flush
18= Maintenance
19= Master: def.
20= Maintenance K1
Parameter Setting/
Data Parameters
010
E6 1. Transmitting relay same options as with E5, sta-
tus 15 = factory setting
Parameter Setting / Data
Parameters
010
