Page 67
9.4.3 Connection for 230V Steam Bath Fans
(Optional)
Risk of electrical shock hazard if not observed!
Use safe low voltage (24V) for the fans and light in the steam cabin.
When employing 230V fans, ensure sufficient distance between the
fans and the steam cabin.In the steam generator, connect exhaust fan
cable to the designated terminals 20 and 21 (230V) and connect sup-
ply fan cable to terminals 20 and 22 (230V). The maximum contact
load per fan is 40 W.
9.5 Cabin Light Installation (Optional)
Cabin lighting may also be connected to the steam generator.
9.5.1 Cabin Light Connection (Optional)
Connect cabin light cable to the designated terminals 13 and 14 (24 V
supply voltage) in the steam generator.
The cabin lighting is protected by a 1.6 A micro fuse. The maximum
contact load is 40 W. Switch lighting on and off using the software key
L on the operating panel.
*: not valid for steam generators type C01 and C02
