17. Technical Specifications
Heater Element Steam Generator
Type HeaterLine
HL06 HL09 HL12 HL18 HL24 HL27 HL30 HL36 HL45
Steam Output [kg/h] 6 9 12 18 24 27 30 36 45
Power Rating [kW] 4,5 6,8 9,0 13,5 18,0 20,3 22,5 27,0 33,8
Power Consumption [A] 11,3 16,8 19,5 29,3 39,0 29,3 39,0 58,5 58,5
Circuit Protection [A] 3x16 3x20 3x25 3x35 3x40 3x35 3x40 3x63 3x63
Electrical Connection* 400V/3/N 50-60Hz
Control Voltage 230V/50-60Hz
*Other voltages upon request.
Heater Element Steam Generator
Type
HeaterCompact
HC02 HC03 HC06 HC06 HC09 HC06
P
HC09
P
HC12 HC18 HC27
Steam Output
[kg/h]
2366969121827
Power Rating
[kW]
1,5 2,25 4,5 4,5 6,8 4,5 6,8 9,0 13,5 20,3
Power Con-
sumption [A]
6,5 9,8 19,6 11,3 16,9 11,3 16,9 19,5 29,3 29,3
Circuit Protec-
tion [A]
1x10 1x10 1x20 3x16 3x20 3x16 3x20 3x25 3x35 3x35
Electrical Supp-
ly*
230V/1/N 400V/3/N 50-60Hz
Control Voltage 230V/50-60Hz
*Other voltages upon request.
Electrode Steam Generator
Type HyLine
HY05 HY08 HY13 HY17 HY23 HY30 HY45
Steam Output [kg/h] 5 8 13 17 23 30 45
Power Rating [kW] 3,8 6,0 9,8 12,8 17,3 22,5 33,8
Power Consumption [A] 5,4 8,7 14,1 18,4 24,9 32,5 48,8
Circuit Protection [A] 3x6 3x10 3x16 3x20 3x35 3x35 3x63
Electrical Connection* 400V/3/N /50-60Hz
Control Voltage 230V/50-60Hz
*Other voltages upon request.
** 1.3-times power consumption after full blow-down. Note overload capacity of automatic breakers. If necessary, select the next
higher rating.
Electrode Steam Generator
TypeCompactLine C01 C02 C06 C10 C17 C22 C30 C45 C58
Steam Output [kg/h] 1,0 2,0 6,0 10,0 17,0 22,0 30,0 45,0 58,0
Power Rating [kW] 0,75 1,5 4,5 7,5 12,8 16,5 22,5 33,8 43,5
Power Consumption [A] 3,3 6,5 6,5 10,8 18,4 23,8 32,5 48,8 62,8
Circuit Protection [A] ** 1x6 1x10 3x10 3x16 3x20 3x35 3x35 3x63 3x63
Electrical Connection* 230V/1/N 400V/3/N/50-60Hz
Control Voltage 230V/50-60Hz
*Other voltages upon request.
**1.3-times power consumption after full blow-down. Note overload capacity of automatic breakers. If necessary, select the next
higher rating.
