7. Basic- DS
If the steam humidifier is equipped with a control type Basic-DS the
Basic-DS-display unit does not include any LC-display or keypad.
Communication between user and steam bath control is thus not possi-
ble. Changing parameters is only possible when connecting an
optional available display (Comfort-DS-display) instead of the Basic-
DS-display.
Chapters „User Mode - Communication with the Control (Comfort-DS/
Comfort Plus-DS) and „Operating Mode - Advanced Communication
wiht the Control (Comfort-DS/ Comfort Plus-DS)“ do not apply to Con-
trol type Basic-DS.
7.1 Basic Construction
The HygroMatik control Type Basic-DS consists of a main PCB and a
display unit with icons to describe the LED.
7.1.1 Basic-DS Display Unit
Using 5 LED, the display unit of the Basic-DS Control provides the user
with information about operational conditions and fault messages:
