13. Basic PCB Connections
Main PCB
B3 transducer (only Humidifier type HyLine, CompactLine
and MiniSteam)
D6 fault indicator lamp (red)
D64 humidify indicator lamp (yellow)
D 63 filling indicator lamp (yellow)
D62 blow-down indicator lamp (yellow)
D61 operating indicator lamp (green)
P1 potentiometer steam generation output limitation; 25 -
100% humidification output
P2 potentiometer pump run time 0 - 45 sec.
6 - 7 sensor electrode input (ST2)
9 main contactor output (ST1)
10 pump output (ST1)
11 solenoid valve output (ST1)
15 - 16 main PCB power supply (ST1)
16 blow-down pump power supply (ST1)
19,17,18 semiconductor relay (ST5) (only Humidifier type HL and
HC)
21 - 24 level switch (ST6) (only Humidifier type HL and HC)
28 - 30 signal relay (collective fault) (ST4)
31 - 42 4 signal relay ouputs (installed on JP3)
JP1 (not used)
ST 8 COM-Port jack
ST 9 remote control jack
JP 9 / JP 4 jumper socket interface driver
JP 5 jumper socket display
JP 3 base socket signal relay PCB
4 - 42 temperature sensor (ST3)
3 24 V DC
2 Input remote switch / safety interlock
