power supply setup
powermax 45 Operator Manual 2-3
Position the power supply
Locate the Powermax45 near an appropriate 200–240volt power receptacle for CSA or CE 1-phase power supplies,
a 400volt receptacle for 3-phase CE power supplies, or a 480volt receptacle for 3-phase CSA power supplies. The
Powermax45 has a 3m (10-foot) power cord. Allow at least 0.25m (10inches) of space around the power supply for
proper ventilation.
Prepare the electrical power
The maximum output voltage will vary based on your input voltage and the circuit’s amperage. Because the current
draw varies during startup, slow-blow fuses are recommended as shown in the following chart. Slow-blow fuses can
withstand currents up to 10times the rated value for short periods of time.
Voltage configurations
The following chart shows the maximum rated output for typical combinations of input voltage and amperage.
Acceptable input voltages can be ±10% of the values given below.
CAUTION
Protect the circuit with appropriately sized time-delay (slow-blow) fuses and a line-disconnect switch.
Model Input voltage Phase Rated output
Input
current at
6kw output
Input
current
during arc
stretch
Recommended
slow-blow fuse
size
CSA
200–240 VAC 1 45 A, 132V 34–28A 55–45A 50 A
208VAC 1 45 A, 132V 33 A 54.5 A 50 A
480VAC 3 45 A, 132V 8.5A 12A 15 or 20*A
CE
200–240 VAC 1 45 A, 132V 34–28A 55–45A 35 or 50*A
400VAC 3 45 A, 132V 10 A 15.5 A 15 or 20*A
CE/CCC
220VAC 1 45 A, 132V 31 A 53 A 35 or 50*A
380VAC 3 45 A, 132V 11 A 14 A 15 A
* Use the higher amperage fuse for applications that require a long arc stretch.

Hypertherm POWERMAX 45 Specifications

General

Output Current	45 A
Rated Output	45 A
Cutting Thickness	12 mm
Severance Thickness	19 mm
Cutting Method	Plasma
Gas Supply	Compressed Air or Nitrogen
Torch Lead Length	7.6 m
