Power suPPly setuP
2-6 powermax 45 Operator Manual
Generator recommendations
Generators used with the Powermax45 should satisfy the following requirements:
CSA
• 1-phase, 50/60Hz, 230/240VAC
• 3-phase, 50/60Hz, 480VAC
CE
• 1-phase, 50/60Hz, 230VAC
• 3-phase, 50/60Hz, 380/400VAC (400VAC recommended for best performance)
Engine
driverating
Engine drive outputcurrent
Performance
(arc stretch)
1-phase
(CSA/CE)
3-phase
(CE)
3-phase
(CSA)
8 KW 33 A 11.5A 10A Good arc stretch at 45A cutting current
6 KW 25 A 9A 7A
Limited arc stretch at 45A cutting current
Good arc stretch at 30A cutting current
Notes: Based on the generator rating, age, and condition, adjust the cutting current as needed.
If a fault occurs while using a generator, turning the power switch quickly to OFF and then to ON again
(sometimes called a “quick reset”) may not clear the fault. Instead, turn the power supply off and wait 30 to
45seconds before turning it on again.
Prepare the gas supply
The gas supply for the Powermax45 can be shop-compressed or cylinder-compressed.A high-pressure regulator must
be used on either type of supply and must be capable of delivering gas to the filter on the power supply at 170l/min at
6.2bar (360scfhat90psi).
WARNING
Do not allow the gas supply pressure to exceed 9.3 bar (135 psi). The filter bowl may explode if this
pressure is exceeded.
If gas supply quality is poor, cut speeds decrease, cut quality deteriorates, cutting thickness capability decreases, and
the life for consumables shortens. For optimum performance, the gas should have a maximum particle size of 0.1micron
at a maximum concentration of 0.1mg/m
3
, a maximum dewpoint of -40°C (-40°F), and a maximum oil concentration of
0.1mg/m
3
(per ISO8573-1 Class1.2.2).
