Hypertherm POWERMAX 45 User Manual

torch setup
3-12 powermax 45 Operator Manual
T45m shielded consumables
Air flowrate (scfh)
Stainless steel
Hot 320
English
Cold 360
Recommended Maximum
Arc
current
(amps)
Material
thickness
Torch-
to-work
distance
(in)
Initial pierce
height
Pierce time
delay
(sec)
Cut
Speed
(ipm)
Voltage
(V)
Cut
Speed
(ipm)
Voltage
(V)
30
0.018 in
(26 Ga)
0.06 0.15 in 250%
0.0
360 117 400* 123
0.030 in
(22 Ga)
340 116 400* 121
0.036 in
(20 Ga)
320 115 400* 119
0.060 in
(16 Ga)
0.2 145 111 185 118
45
0.036 in
(20 Ga)
0.06
0.15 in 250%
0.0
300 115 400* 109
0.060 in
(16 Ga)
320 116 400* 125
0.075 in
(14 Ga)
0.1 280 117 360 115
0.105 in
(12 Ga)
0.3 160 117 200 116
0.135 in
(10 Ga)
0.4 120 117 150 118
0.188 in
(3/16 in)
0.5 70 118 85 118
0.250 in
(1/4 in)
0.6 44 120 55 120
0.375 in
(3/8 in)
0.8 30 122 32 121
0.500 in
(1/2 in)
Edge start recommended
14 132 18 128
0.750 in
(3/4 in)
7 140 9 131
*Maximum cut speed is limited by the test table’s maximum speed (400 ipm).
