TORCH SETUP
3-22 powermax 45 Operator Manual
Recommended Maximum
Arc
current
(amps)
Material
thickness
(in)
Torch-
to-work
distance
(in)
Initial pierce
height
Pierce
time delay
(sec)
Cut
Speed
(ipm)
Voltage
(V)
Cut
Speed
(ipm)
Voltage
(V)
30
0.018
(26 Ga)
0.02 0.1 in 500%
0.0
350 105 400* 98
0.030
(22 Ga)
320 102 400* 103
0.036
(20 Ga)
280 101 350 100
0.060
(16 Ga)
0.2 175 97 220 100
0.075
(14 Ga)
0.4
120 98 150 97
0.105
(12 Ga)
80 96 100 96
0.135
(10 Ga)
50 100 65 101
T30v (Powermax30) 30 A consumables
Mild steel
English
Air flowrate (scfh)
Hot 280
Cold 310
*Maximum cut speed is limited by the test table’s maximum speed (400 ipm).
