1 © 2012 Installation and Reference Manual D0125 Rev.H
SlideDriver Models
HySecurity manufactures many hydraulic slide gate operator models to suit the desired gate panel size,
weight and speed. This manual should be used for the SlideDriver VF operators only. Identify your operator
model and note the changes in instructions and final adjustments.
SlideDriver 50VF2
(222 X2)
SlideDriver 50VF2-EFO
(222 X2EFO)
SlideDriver 50VF3
(222 X3)
General
Commercial industrial,
high security
Commercial industrial, high security
Commercial industrial, high security
Gates
Variable frequency drive
(easy start and stop)
heavy gates (5,000 lbs)
and fast (26 in/s).
Variable frequency drive (easy start
and stop) heavy gates (5,000 lbs).
Opens and closes at 26in/s.
Emergency Close at 36in/s on
constant HOLD command.
Variable frequency drive
(easy start and stop)
heavy gates (5,000 lbs)
and fast (36in/s).
Duty
Continuous
Continuous
Continuous
Modular
50VF2-M
50VF2/3-EFO-M
50VF3-M
Correctional
Facility
50VF2-C
50VF2/3-EFO-C
50VF3-C
Horsepower
2 hp
2 hp
2 hp
Speed
26in/s
26in/s, Emergency Close: 36in/s
36in/s
Soft Stop
yes
yes
yes
Brake Valves
yes
yes
yes
Soft Start
ultra soft start and stop
ultra soft start and stop
ultra soft start and stop
Drawbar Pull
300lbs (136kg)
300lbs (136kg)
300lbs (136kg)
Gate Weight
Max. Capacity
5,000lbs (2.3MT)
5,000lbs (2.3MT)
5,000lbs (2.3MT)
Drive Wheels
Two 8in. (20.3cm)
drive wheels
Two 8in. (20.3cm)
drive wheels
Two 8in. (20.3cm)
drive wheels
UL Class
III, IV
III, IV
III, IV
Warranty
5 years
5 years
5 years
*Accessory item: Remote Release
