Table 3. Specications for a dual-socket utility node (continued)
Storage SATA Connector: Two optional
SFF-8654 ports for 12 front SATA
Controller: Direct from AMD
EPYC CPU
Speed: 6 Gbs
RAID: N/A
NVMe Connector U.2: Two optional
SFF-8654 ports for four front
NVMe
Connector M.2: Two
22110/2280 (by PCIe Gen 4
interface)
Graphic Connector type D-Sub 15-pin
Resolution Up to 1920 x 1200
Chipset Aspeed AST2500
I/O ports USB (For service use only.)
• Two USB 3.1 Gen 1 ports (at
front)
• Two USB 3.1 Gen 1 ports (at
rear)
VGA One D-Sub 15-pin port
RJ-45
• Two 10 GbE ports
• One 1 GbE dedicated for IPMI
System monitoring Chipset Aspeed AST2500
Temperature Monitors temperature for CPU
and memory and system
environment
Voltage Monitors voltage for CPU,
memory, chipset, and power
supply
LED Over temperature warning
indicator, fan and PSU fail LED
indicator.
Others Watchdog timer support
Server management Onboard chipset Onboard Aspeed AST2500
AST2500 iKVM feature 24-bit high-quality video
compression. Supports storage
over IP and remote platform-
flash, USB 2.0 virtual hub.
AST2500 IPMI feature IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC
interface
Chapter 2. Technical overview23
