Appendix B. PCIe Gen 4 x16 2-port HDR 100 Gb
InniBand ConnectX-6 adapter (FC EC6G; CCIN
590E)
Learn about the specications and operating system requirements for feature code (FC) EC6G.
Overview
FC EC6G is a low-prole adapter. The PCIe Gen 4 x16 2-port high data rate (HDR) 100 Gb InniBand (IB)
ConnectX-6 adapter is a PCI Express (PCIe) generation 4 (Gen 4) x16 adapter. This adapter can be used
in a x16 PCIe slot in the system. The adapter enables higher HPC performance with new Message Passing
Interface (MPI) offloads, such as MPI Tag Matching and MPI AlltoAll operations, advanced dynamic
routing, and new capabilities to perform various data algorithms. The HDR 100 Gb adapter supports
connecting to an HDR 200 Gb switch by using HDR 100 Gb splitter cables such as Direct Attach Copper
(DAC) or Active Optical Cables (AOC). Splitter cables allow a single HDR 200 Gb switch port to connect to
HDR 100 Gb ports, doubling a typical HDR switch capacity from 40 ports to 80 ports. The HDR 100 Gb
adapter also supports enhanced data rate (EDR) copper and optical cables when connecting to EDR 100
Gb or HDR 200 Gb InniBand switches. For more information about cables, see the cable matrix
table.
Note: The Virtual Protocol Interconnect (VPI) feature is supported on this adapter. The adapter may be
used as an InniBand adapter or an Ethernet adapter.
Figure 54. 2-port HDR 100 Gb InniBand ConnectX-6 adapter (FC EC6G)
Specications
The adapter specications are as follows:
Adapter FRU number
02CM912
I/O bus architecture
PCIe4 x16
©
Copyright IBM Corp. 2022, 2023 77
