Slot requirement
For more information about slot priorities, maximums, and placement rules, see PCIe adapter
placement rules and slot priorities and select the system that you are working on.
Cables
Specic X, YO, or AA SAS cable features with new narrow HD connectors are used to attach to the
other adapter or disk expansion drawers.
Internal SAS device attachment on a 9040-MR9 system requires specic AZ cables that are provided
with the subsystem or device features that are being attached. Special cabling is required for multi-
initiator and high availability congurations. For more information, see Serial attached SCSI cable
planning.
Voltage
3.3 V
Form factor
Short, low-prole but packaged for full-height installations.
Maximum number
For the maximum adapters supported, see the PCI adapter placement topic collection for your
system.
Attributes
• Four external mini SAS HD 4x connectors provide attachment of SAS device enclosures
• SAS Serial SCSI Protocol (SSP) and Serial Management Protocol (SMP)
• RAID 0, 5, 6, or 10 with hot-spare capability. System level mirroring through the operating system is
also supported. JBOD functionality (512 byte) is supported in a single controller conguration only.
• Concurrent rmware update
• Support for multi-initiator and high availability or single controller congurations
Other important requirements for adapter installation
An automatic sector conversion takes place for use with the new adapter when migrating existing SAS
disk enclosures and devices from existing previous PCIe SAS adapters to PCIe3 SAS adapters. For more
information about the migration procedures, see Upgrading a SAS RAID storage adapter
.
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
This adapter requires the following AIX driver: devices.pciex.14104a03.device driver package
140
Power Systems: Managing PCIe adapters
