Form factor
Short, low-prole (FC EC2T).
Short, with full-height tailstock (FC EC2U).
Attributes provided
RDMA over Converged Ethernet (RoCE).
Dual port 25 Gb/10 Gb Ethernet network connectivity.
Supports 25 Gb Ethernet SFP28 connectivity.
Supports 10 Gb Ethernet SFP+ connectivity.
Supports 25 Gb SFP28 SR connectivity with a 25 Gb optical transceiver (IBM
®
P/N 77P5153,
purchased separately).
Supports 10 Gb SFP+ SR connectivity with a 10 Gb optical transceiver (IBM
®
P/N 77P9336, purchased
separately).
AIX
®
Network Installation Management (NIM) support.
PCI Express 3.0 (up to 8 GT/s) x8.
PCIe Gen 3.0 compliant, 1.1 and 2.0 compatible.
IEEE 802.3ae (25Gb or 10Gb Ethernet), IEEE 802.3ad (Link Aggregation & Failover), IEEE 802.3az
(Energy Efcient Ethernet), IEEE 802.1Q/P (VLAN Tagging), IEEE 802.10au (Congestion Notication),
IEEE 802.1Qbg, IEEE 802.3Qaz D0.2 (ETS), IEEE 802.1Qbb D1.0 (PFC), IEEE 1588v2 (PTP).
Jumbo frame support up to 9.6 KB.
VXLAN and NVGRE Overlay Network offload support.
TCP/UDP/IP stateless offload.
TCP/UDP checksum offload.
TCP segmentation offload.
PowerVM SR-IOV support.
Cables
For 25 GbE, IBM
®
offers SFP28 Passive Copper 25 Gb Ethernet cables up to 2 m. SFP28 based
transceivers are included on each end of these cables.
For 10 GbE, IBM
®
offers Direct Attach Copper (DAC) cables up to 5 m. SFP-based transceivers are
included on each end of these cables. For more information about adapter cabling, see “Cable and
Transceiver information” on page 84.
Transceivers
For 25 GbE, IBM
®
qualies and supports SFP28 optical transceiver (FC EB47) to install into the
adapter. Customers can also use their own optical cabling and SFP28 optical transceiver for the other
end. The 25 Gb optical transceiver is capable up to 100 m through the OM4 cable or 70 M through
OM3 cable. Either one or both of the adapter’s two SFP28 ports can be populated.
For 10 GbE, IBM
®
qualies and supports SFP+ optical transceiver (FC EB46) to install into the adapter.
Customers can also use their own optical cabling and SFP+ optical transceiver for the other end. The
10 Gb optical transceiver is capable up to 300 M through the OM3 cable or 82 m through OM2 cable.
Either one or both of the adapter’s two SFP28 ports can be populated.
Cable and Transceiver information
Use multimode ber optic cables with shortwave lasers that adhere to the following specications:
• OM3 or OM4: Multimode 50/125 micron ber, 2000 MHz x km bandwidth
• OM2: Multimode 50/125 micron ber, 500 MHz x km bandwidth
• OM1: Multimode 62.5/125 micron ber, 200 MHz x km bandwidth
Because core sizes are different, OM1 cables can only be connected to other OM1 cables. For best
results, OM2 cables must not be connected to OM3 or OM4 cables. However, if an OM2 cable is
connected to an OM3 or OM4 cable, the characteristics of the OM2 cable apply to the entire length of the
84
Power Systems: Managing PCIe adapters
