010 (continued)
– Select Advanced Diagnostics on the menu.
– Select System Info on the menu.
– Select Hardware Config on the menu.
– Compare the Hardware Configuration Report screen with the actual
devices installed in the system unit.
Note: If necessary, remove the cover and visually compare the devices
installed in the system unit to those shown in the Hardware
Configuration Report.
DOES THE HARDWARE CONFIGURATION REPORT CORRECTLY
IDENTIFY THE DEVICES INSTALLED IN THE SYSTEM UNIT?
Yes No
011
– The Hardware Configuration Report shows only those devices
supported by the Diagnostics and Utilities CD and only
factory-installed devices for the model you are servicing.
– If a device is missing from the list and is not factory installed, refer
to the service manual provided for that device. (Refer to the
Appendix B, “Model/Monitor Configurations and FRU Part Numbers”
on page B-1 to determine the factory-installed devices in the model
you are servicing.)
– If a factory-installed drive device or adapter card is not listed in the
Hardware Configuration Report, go to either “Diagnostics for
Factory-Installed Drive Devices Not Supported by the Diagnostics
and Utilities CD” on page 2-49 or “Diagnostics for Factory-Installed
Riser Card, Sound Card, or Adapter Cards Not Supported by
Diagnostics and Utilities CD” on page 2-52.
012
– Select Diagnostics Menu from the menu.
– Select Easy Test Diagnostics from the menu.
DOES THE EASY TEST DIAGNOSTICS FINISH WITHOUT ERROR
CODES?
Yes No
013
– If the last test stops and you cannot continue, first make sure all
switches, power connectors, cables, and jumpers are set correctly
and show the correct voltages and continuity.
(Step 013 continues)
Check Procedures 2-7
To Next Page
