(continued)
DOES THE HARDWARE CONFIGURATION REPORT CORRECTLY
IDENTIFY THE DEVICES INSTALLED IN THE SYSTEM UNIT?
Yes No
007
– The Hardware Configuration Report shows only those devices
supported by the Diagnostics and Utilities CD and only
factory-installed devices for the model you are servicing.
– If a device is missing from the list and is not factory installed, refer
to the service manual provided for that device. (Refer to the
Appendix B, “Model/Monitor Configurations and FRU Part Numbers”
on page B-1 to determine the factory-installed devices in the model
you are servicing.)
– If a factory-installed drive device or adapter card is not listed in the
Hardware Configuration Report, go to either “Diagnostics for
Factory-Installed Drive Devices Not Supported by the Diagnostics
and Utilities CD” on page 2-49 or “Diagnostics for Factory-Installed
Riser Card, Sound Card, or Adapter Cards Not Supported by
Diagnostics and Utilities CD” on page 2-52.
008
– Select Diagnostics Menu from the Main Menu.
– Select Easy Test Diagnostics from the Diagnostics Menu.
DOES THE EASY TEST FINISH WITHOUT ERROR CODES?
Yes No
009
– If the last test stops and you cannot continue, first make sure all
switches, power connectors, cables, and jumpers are set correctly
and show the correct voltages and continuity.
– Make note of any messages, error codes, beeps, or new symptoms.
Go to “Index of Symptoms, Messages, Error Codes, or Beeps” on
page 2-9.
010
– The Easy Test Diagnostics did not detect a failure. If the system still
display a failure:
Check all adapter card jumper settings.
Check all adapter card switch settings.
(Step 010 continues)
2-44
To Next Page
