009 (continued)
DOES THE SYSTEM UNIT FAIL TO SHUT OFF WHEN THE ON/OFF
SWITCH IS PRESSED?
Yes No
010
Go to Step 006 on page 2-27.
011
– You may have a failing on/off switch cable assembly.
Note: The J29 and J30 power and switch connectors are latched. To
remove a latched connector, press in the latch using the tip of a
screwdriver to release the connector.
– Disconnect the J29 switch connector on the system board and take an
ohm reading between the two pins of connector J29.
DO YOU HAVE AN OHM READING WHEN THE SWITCH IS PRESSED
AND AN OPEN READING WHEN THE SWITCH IS RELEASED?
Yes No
012
– Replace the on/off switch cable assembly.
013
– Replace the system board.
Check Procedures 2-29
To Next Page
