IBM eserver pSeries 7311 D10 User Manual

3) Align the top of the bezel assembly into the grooves on the top of the
cassette assembly and then push the bezel onto the cassette linkage until
the tab on the top of the bezel is seated in the recess of the cassette
assembly.
Recess
Groove
Ta b
Bezel Assembly
4) Insert the two tabs on the bezel extension into the two slots on the cassette
assembly.
Tabs
Chapter 8. Removal and Replacement Procedures 113
