k. Check for the following:
1) Ensure that extension arm engages the pins on the cassette. You should
be able to see the pins through the holes in the arm. The bezel tab should
be seated as shown in the following figure.
Pin
Pin
Pin
2) Ensure the cover arm latch is completely pressed into the hooked slot on
the bezel as shown.
114 Eserver pSeries 7311 Model D10 and Model D20 Service Guide
