Four I/O Subsystems, Eight I/O Subsystems: The illustration on the left shows four
I/O subsystems connected to the processor subsystem using one SPCN loop. The
illustration on the right shows eight I/O subsystems connected to the processor
subsystem using one SPCN loop.
