Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and
replace/recovery
procedure
C08 ports HSL ports See Figure 7. FC 9079
base I/O tower - HSL and
SPCN locations (See page
) below.
N/A N/A
C09 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C10 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C11 PCI card The failing component is
either an:
1. IOP
2. Integrated xSeries
Server (IXS)
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. 2890 (See page 527) or
2892 (See page 527)
Note: When the IXS
card is installed in this
position, concurrent
maintenance at the card
position is not
recommended.
If IXS, then go to Models
840/SB3, FC 8079 (lower
half), FC 9079 Cards —
Dedicated. Otherwise, go to
Models 840/SB3, FC 8079
(lower half), FC 9079 Cards
(concurrent).
C12 PCI card (if
no IXS in
C11)
The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C13 PCI card
(Short if
2890 IXS in
C11)
IOA See Type, model, and part
number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C14 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
280 Hardware (Remove and Replace; Part Locations and Listings)
