Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and
replace/recovery
procedure
C02 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Dedicated.
C03 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Dedicated.
C04 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Dedicated.
C05 PCI card The failing component is
either an:
1. IOP
2. Integrated xSeries
Server (IXS)
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. 2890 (See page 527) or
2892 (See page 527)
Note: When the IXS
card is installed in this
position concurrent
maintenance at the card
position is not
recommended.
If IXS, then go to Models
840/SB3, FC 8079 (lower
half), FC 9079 Cards —
Dedicated. Otherwise, go to
Models 840/SB3, FC 8079
(lower half), FC 9079 Cards
(concurrent).
C06 PCI card (if
no IXS in
C05)
The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C07 PCI card
(Short if
2890 IXS in
C05)
IOA See Type, model, and part
number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
C08 HSL I/O
bridge card
v High-speed link I/O
bridge
v PCI host bridge
v 2691 (See page 524)
v See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Dedicated.
Analyze hardware problems 279
