7. Multi-adapter bridge domains are labeled PCI Bridge Set inside the tower.
8. The following table provides information necessary to identify the IOP to which IOAs are assigned.
v The left column indicates the domain in which IOA assignment is allowed.
v The right column is used to determine the IOP to which an IOA is assigned.
v The first position in the list must be an IOP. The remaining positions may be IOPs or IOAs. IOAs are
assigned to the first IOP located to their left in the list. Although IOAs can be manually reassigned
using SST/DST, the IOA assignments return to the default order after each IPL.
Table 2. Identify the IOP to which IOAs are assigned
Multi-adapter bridge domain / PCI bridge set IOA assignment rules
C01 - C04 C01, C02, C03, C04
C05 - C10 C05, C06, C07, C08, C09, C10
C11 - C15 C11, C12, C13, C14, C15
Table 3. FRU locations and failing components for FC 9079 base I/O tower table
Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and
replace/recovery
procedure
D01 - D40 Disk unit Disk unit See Type, model, and part
number list.
Go to Recovery procedures.
D41 Optical Optical See Type, model, and part
number list.
Go to FC 5074, FC 5079,
FC 9079 - Removable media
- D41 and D42.
D42 Tape Tape See Type, model, and part
number list.
Go to FC 5074, FC 5079,
FC 9079 - Removable media
- D41 and D42.
D46 - D50 Disk unit Disk unit See Type, model, and part
number list.
Go to Recovery procedures.
NB1 Control panel Control panel 24L0945 Go to FC 5074, FC 5079 -
Control panel - NB1.
DB3 Device board Device board 283C (See page 526) or
28CB (See page 528)
Go to FC 5074, FC 5079,
FC 9079 - Device board -
DB3.
DB2 Device board Device board 283D (See page 526) or
28CC (See page 528)
Go to FC 5074, FC 5079,
FC 9079 - Device board -
DB1 and DB2.
DB1 Device board Device board 283D (See page 526) or
28CC (See page 528)
Go to FC 5074, FC 5079,
FC 9079 - Device board -
DB1 and DB2.
B01 and
B02
AMD AMD 04N3345 Go to FC 5074/5079, FC
9074, FC 9079 - AMD - B01
and B02.
C01 PCI card IOP 2842 (See page 527), 2843
(See page 527), or 2844
(See page 527)
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Dedicated.
278 Hardware (Remove and Replace; Part Locations and Listings)
