Index Part number Units Description
53 53P4651 1 Power sub frame assembly
54 1621811 12 Screw, M4 (10mm)
55 97H7318 1 Battery pack - This part
number includes four
batteries. Refer to the
BATRY symbolic FRU for
additional information.
56 1621811 12 Screw, M4 (10mm)
57 24L0940 AR Filler, Spacer
58 1621811 2 Screw, M4 (10mm)
59 NONUM 1 EMC access plate
60 1621811 2 Screw, M4 (10mm)
61 24L0939 AR Filler, power supply
62 1621811 2 Screw, M4 (10mm)
63 44H8641 2 Cable Clamp, To p
64 44H8640 2 Cable Clamp, Base
65 1621811 2 Screw, M4 (10mm)
66 97H7316 1 Battery charger
67 1621811 4 Screw, M4 (10mm)
68 90H6629 3 Power supply — 765 watts
(P01, P02, P03)
Part assemblies - Models 840/SB3: For use by authorized service providers.
Cover assembly (processor tower)
Final assembly (front) (processor tower)
Final assembly (rear) (processor tower)
Control panel (processor tower)
Cover assembly (with FC 9079)
Final assembly (with FC 9079)
Cover assembly - Models 840 and SB3 processor tower: For use by authorized service providers.
Figure 1. Cover assembly - Models 840 and SB3 processor tower
Analyze hardware problems 409
