Index Part
number
Units Description
1 53P0330 1 Display panel tray assembly
2 NONUM 1 Display panel enclosure assembly
3 53P0320 5 Screw
4 53P0308 1 Cover, Display panel
5 53P0280 1 Cover, top
6 53P0320 2 Screw
7 53P0285 1 Cover, left side
8 53P0320 2 Screw
9 53P0303 1 Cover assembly, back
10 53P0286 1 Cover assembly, right side
11 53P0320 2 Screw
12 53P0322 1 EMC bracket
13 06P5858 1 Latch housing
14 03K9553 2 Screw, M3.5 x 7
15 06P5857 1 Latch handle
16 53P0234 1 Bracket, DASD filler
17 44H7336 4 Screw
18 53P1359 1 Cover assembly, front
Final assembly - FC 5095 Expansion I/O Tower: For use by authorized service providers.
Figure 1. Final assembly - FC 5095 Expansion I/O Tower
472 Hardware (Remove and Replace; Part Locations and Listings)
