Table 1. Final assembly - FC 5095 Expansion I/O Tower
Index Part numbers Units Description
19 21P3593 AR Disk unit
19 24L0900 AR Disk unit
20 53P0250 2 Disk unit enclosure
21 44H7366 AR Screw, M3.5 x 8mm
21 53P0319 AR Screw
22 97P3138 2 Disk unit enclosure backplane
23 53P0321 8 Screw
24 53P0262 1 EMC enclosure
25 53P0262 4 Air moving device (Blower assembly)
Figure 2. Final assembly - FC 5095 Expansion I/O Tower, continued
Analyze hardware problems 473
