Table 1. Service Processor Checkpoints (continued)
Checkpoint Description Action/
Possible Failing FRU
A807 Flash area not usable See note 1
A808 Flash error log to debug port See note 1
A809 Flash erase start See note 1
A80A Flash erase end See note 1
A80B Reserved; not used See note 1
A80C Reserved; not used See note 1
A80D Reserved; not used See note 1
A80E Reserved; not used See note 1
A80F Service processor dump done See note 1
B00B Firmware delaying to determine
if MOPs error is the result of
power disturbance. After delay,
SPCN is queried for CEC
power status.
1. Remove, then reapply
power to the system.
2. Call service support.
B0F5 Delayed power-off sequence
has begun
See note 1
B0FA Delayed power-off
acknowledged
See note 1
B0FF Power-off requested program
executing
See note 1
Notes:
1. If the system fails to progress after this checkpoint is put in the display, do the following:
a. Activate the service processor pinhole reset switch on the system’s operator panel.
b. If the hang repeats, check with service support to see if there is a firmware update that fixes the
problem.
c. If not, or the update does not fix the problem, change the primary I/O backplane.
d. If this procedure does not fix the problem, call service support.
2.
If the system fails to progress after this checkpoint is put in the display, do the following:
a. Activate the service processor pinhole reset switch on the system’s operator panel.
b. If the hang repeats, check with service support to see if there is a firmware update that fixes the
problem.
c. If not, or the update does not fix the problem, go to “MAP 1540: Minimum Configuration” on page
110.
d. If this procedure does not fix the problem, call service support.
3.
Recovery mode flash update has failed. Do the following:
a. Activate the service processor pinhole reset switch on the system’s operator panel and try the
recovery mode flash update again.
b. If the system hangs again, make a new set of firmware update diskettes, using new, blank
diskettes. Retry the flash update with the new diskettes.
c. If the same hang occurs with the new diskettes, replace the following FRUs one at a time in this
order:
1) Diskette drive
2) I/O backplane in the primary I/O drawer
d. If this procedure does not fix the problem, call service support.
4.
The service processor was unable to configure the modem(s) attached to the serial port(s). Do the
following:
142 Service Guide
