Table 2. Firmware Checkpoints (continued)
Checkpoint Description Action/
Possible Failing FRU
E5xy
(E511 - E5FF)
Where x is not
equal to 0, and y is
not equal to 0.
Configure remote I/O
subsystem components
The E5xy (E511 to E5FF)
codes are reserved for
activities relating to
configuration or testing of the
I/O subsystem, or remote I/O
subsystem. A hang at one of
these codes implies that a
severe error occurred during
the programming of I/O
subsystem registers or when
interacting with adapters
plugged into the system. The
last two digits in the
checkpoint can be used to
help isolate the location of
the I/O activity that caused
the problem.
“x” indicates the I/O drawer
number. “y” indicates the PCI
bus occurrence.
If y =_, then the PCI bus is:
Y = PCI bus
1 = 0
2 = 1
3 = 2
4 = 3
See “AIX and Physical
Location Code Tables” in
Chapter 1, for location codes.
Using the information above,
go to “MAP 1540: Minimum
Configuration” on page 110.
E600 SSA PCI adapter open firmware
has run successfully.
Replace the adapter. See
“Determining Location Code”
on page 160 for location
code information related to
this error.
E601 SSA PCI adapter BIST has
started but failed to complete
after four seconds.
Replace the adapter. See
“Determining Location Code”
on page 160 for location
code information related to
this error.
E602 SSA PCI adapter open firmware
has started.
Replace the adapter. See
“Determining Location Code”
on page 160 for location
code information related to
this error.
E603 SSA PCI adapter BIST has
completed with an error.
Replace the adapter. See
“Determining Location Code”
on page 160 for location
code information related to
this error.
Chapter 4. Checkpoints 153
