Table 5. SPCN Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
1011 2600 Pgood fault Primary I/O backplane
Location: U0.1-P1
1011 2601 Pgood fault Primary I/O backplane
Location: U0.1-P1
1011 2602 CEC power domain fault 1. Check VS COMM and SPCN connections
2. Reseat CEC drawer
3. Check input power to power supplies
Locations: U1.1-V1
U1.1-V2
4. CEC power supplies
Locations: U1.1-V1
U1.1-V2
5. CEC backplane
Location: U1.1-P1
6. Primary I/O backplane
Location: U0.1-P1
1011 2603 Primary I/O drawer power domain fault 1. Check input power to power supplies
Locations: U0.1-V1
U0.1-V2
2. Check VS COMM and SPCN connections
3. Reseat CEC drawer
4. Primary I/O drawer power supplies
Locations: U0.1-V1
U0.1-V2
5. I/O Drawer power distribution board
Location: U0.1-X1
6. Primary I/O backplane
Location: U0.1-P1
1011 2604 Power domain fault in CEC and primary I/O
drawers
See error codes 1011 2602 and 1011 2603
1011 2610 Missing or unplugged memory Inspect system memory in the CEC drawer
for proper installation of DIMMs and memory
riser cards.
Location: U1.1
1011 2611 Regulator fault
1. Verify that the VSCOMM cable is
functioning and properly installed.
2. Replace the primary I/O drawer
backplane
Location: U0.1-P1.
1011 2612 SPCN problem
1. Verify that the VSCOMM cable is
functioning and properly installed.
2. Replace the primary I/O drawer
backplane
Location: U0.1-P1.
1011 2613 Power configuration fault 220V ac required
1011 3100 I2C controller fault Primary I/O backplane
Location: U0.1-P1
1011 3101 I2C bus 1 fault 1. Primary I/O drawer operator panel
Location: U0.1-L1
2. Primary I/O backplane
Location: U0.1-P1
Chapter 5. Error Code to FRU Index 169
