Table 5. SPCN Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
1011 7720 Slow CEC fan 2 1. Fan 2
Location: U1.1-F2
2. Primary I/O backplane
Location: U0.1-P1
1011 7721 Missing CEC fan 2 Fan 2
Location: U1.1-F2
1011 7731 Missing CEC fan 3 - invalid error on this
system
If this error code occurs, it indicates that the
I/O type of the primary I/O drawer planar is
not correct. For more information on setting
the I/O type, see ″Power Control Network
Utilities Menu″ on page378.
1011 8400 VPD configuration problem Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 8401 VPD access problem Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 8402 VPD access problem Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 8403 VPD level mismatch Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 8404 PU 2 mismatch 1. Processor card
Location: U1.1-P1-C2
2. Primary I/O backplane
Location: U0.1-P1
1011 8409 Processor card VPD problem 1. Ensure that the processor card(s) are the
right type for the system and that they are
properly installed.
2. CEC processor card
Locations: U1.1-P1-C1
U1.1-P1-C2
1011 840A VPD +5 stuck high Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 840B VPD +5 stuck low Ignore all location codes.
Go to MAP 1540 and run CEC minimum
configuration.
1011 840C Memory DIMM misplugged Inspect system memory in the CEC drawer
for proper installation of DIMMs and memory
riser cards.
Location: U1.1
1011 840D I/O type mismatch 1. Check cabling
2. From the main service processor menu,
select the System Information Menu,
then select the Power Control Network
Utilities Menu. Use option three to set
the I/O type to 84. Reboot the system.
3. Primary I/O drawer backplane
Location: U0.1-P1
172 Service Guide
