Table 5. SPCN Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
1011 9013 Invalid address 1. Check SPCN cabling
2. Primary I/O backplane
Location: U0.1-P1
1011 9014 Invalid address mode Update system firmware
Location: U0.1-P1/Y1
1011 9038 Node fault Primary I/O backplane
Location: U0.1-P1
1011 9039 Node fault Primary I/O backplane
Location: U0.1-P1
1011 9042 EEPROM failure Primary I/O backplane
Location: U0.1-P1
1011 9043 Download failure 1. Check for system firmware update
2. Call second level of support
1011 9046 QDS packet sequence error 1. Check for system firmware update
2. Call second level of support
1011 9047 QDS block sequence error 1. Check for system firmware update
2. Call second level of support
1011 9080 Undefined status code received Primary I/O backplane
Location: U0.1-P1
1011 90F0 CEC drawer not present in configuration table 1. Check SPCN cabling
2. Reset system and reboot
3. Primary I/O backplane
Location: U0.1-P1
1011 9101 SPCN failed to respond to service processor
in time
Primary I/O backplane
Location: U0.1-P1
1011 9102 Permanent address assignment failed Primary I/O backplane
Location: U0.1-P1
1011 9103 Download initialize timeout Primary I/O backplane
Location: U0.1-P1
1011 9104 Download completion timeout Primary I/O backplane
Location: U0.1-P1
1011 9105 Load damaged timeout Primary I/O backplane
Location: U0.1-P1
1011 9109 Download failure Primary I/O backplane
Location: U0.1-P1
1011 9111 Network too large for service processor 1. Check for system firmware update
2. Call second level of support
1011 9114 Firmware image corrupted 1. Reinstall system firmware
2. Primary I/O backplane
Location: U0.1-P1
1011 9116 SPCN communication with operator panel
failure
1. Primary I/O drawer operator panel
Location: U0.1-L1
2. Primary I/O backplane
Location: U0.1-P1
1021 00AA System power control network firmware
update started (no error)
Informational message
