Table 6. Firmware Error Codes. (continued)
Error Code Description Action/
Possible Failing FRU
203w 0xyz Remote I/O (RIO) configuration warning. This code indicates that an RIO configuration
was detected that does not result in complete
loops. The system continues to boot,
however performance or recovery capability
may be reduced. In some cases, the problem
may result in missing I/O. Remote I/O
drawers are connected in loops. Use the
letters w, y, and z in the error code to isolate
the location of the open loop. Check RIO
cables for loose connections, and verify
power on the I/O drawers by the presence of
fan motion.Go to “MAP 1540: Minimum
Configuration” on page 110.
Note:
The following numbers may be used to help
isolate the failing component.
v w = loop number, this is either 0 or 1 in a
system with 2 RIO loops.
v x = Always 0.
v y is either 1 or 2 on a system with 2 loops.
y indicates the nearest associated RIO
port number on the CEC drawer according
to the following table:
y = Nearest RIO Port
1 = 0
2 = 1
3 = 2
4 = 3
v z = B, indicates a missing return line from
the I/O drawer to the CEC drawer.
v z = C, indicates a missing link between
two I/O drawers.
v z = E, indicates an I/O drawer was found
connected to RIO port 3 with no return to
the CEC drawer, and no I/O drawer was
found connected to RIO port 2. In this
case, the I/O connected to RIO port 3 is
removed from the configuration since the
cause of the error and the proper location
of the I/O cannot be determined.
20A8 0000 Insufficient information to boot. Verify the IP address.
20A8 0001 Client IP address is already in use by other
network device
Change IP address.
20A8 0002 Cannot get gateway IP address Refer to Table 2 on page 145 using code
E174.
20A8 0003 Cannot get server hardware address Refer to Table 2 on page 145 using code
E174.
20A8 0004 Bootup failed Refer to Table 2 on page 145 using code
E175.
20A8 0005 File transmission (TFTP) failed. Check network connection, try again.
20A8 0006 Boot image too large Contact your next level of support for
assistance.
Chapter 5. Error Code to FRU Index 195
