Table 6. Firmware Error Codes. (continued)
Error Code Description Action/
Possible Failing FRU
20D0 0xxx Unknown/unrecognized device
20D0 000F Selftest failed on device, no error and/or
location code information available
Refer to “Determining Location Code” on
page 160 to see if a location code is
available for the device the error was
reported against.
1. Replace device indicated by the location
code (if available).
2. Go to “MAP 1540: Minimum
Configuration” on page 110
20D0 0010 Selftest failed on device, can’t locate package Contact your service support representative
for assistance.
20D0 0011 Firmware RTAS attempt to allocate memory
failed.
Contact your next level of support for
assistance.
20E0 0xxx Security
20E0 0001 Privileged-access password entry error. The password has been entered incorrectly.
Retry installing the password.
20E0 0004 Battery drained or needs replacement 1. Replace battery
Location:
U0.1-P1-V3
2. Replace Primary I/O drawer backplane
Location: U0.1-P1
20E0 0009 Invalid password entered - system locked The password has been entered incorrectly 3
times.
Turn off, then turn on the system unit, then
enter the password correctly.
20EE 0xxx Informational
20EE 0003 IP parameter requires 3 dots ″.″ Enter valid IP parameter.
Example: 000.000.000.000
20EE 0004 Invalid IP parameter Enter valid IP parameter.
Example: 000.000.000.000
20EE 0005 Invalid IP parameter (>255) Enter valid IP parameter.
Example: 255.192.002.000
20EE 0006 No recognized SCSI adapter present This warning occurs when the selected SMS
function cannot locate any SCSI adapter
supported by the function. If a supported
SCSI adapter is installed:
1. Replace SCSI adapter(s).
2. Replace the I/O drawer backplane in
drawer(s) containing SCSI adapter(s).
20EE 0007 Keyboard not found 1. Plug in keyboard.
2. Replace primary I/O drawer backplane
Location: U0.1-P1
196 Service Guide
