Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4066 0238 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 32, riser 1
Location: U1.1-P1-M1.32
4066 023D Scan interface basic assurance tests
detected memory DIMM group fault
Memory octal D, riser 1
Location: U1.1-P1-M1.7 x8
4066 023E Scan interface basic assurance tests
detected memory DIMM group fault
Memory quad D odd, riser 1
Location: U1.1-P1-M1.7 x4
4066 023F Scan interface basic assurance tests
detected memory DIMM group fault
Memory quad D even, riser 1
Location: U1.1-P1-M1.8 x4
4066 02FF Scan interface basic assurance tests
detected memory on riser fault
All memory on riser 1
Location: U1.1-P1-M1.1 x32
Memory failure on riser card 1 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4066 0300 Scan interface basic assurance tests
detected processor card fault
Processor card
Location: U1.1-P1-C1
4066 0400 Scan interface basic assurance tests
detected processor card fault
Processor card
Location: U1.1-P1-C2
4066 0500 Scan interface basic assurance tests
detected memory riser card fault
Memory riser card 2
Location: U1.1-P1-M1
4066 0501 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 1, riser 2
Location: U1.1-P1-M2.1
4066 0502 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 2, riser 2
Location: U1.1-P1-M2.2
4066 0503 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 9, riser 2
Location: U1.1-P1-M2.9
4066 0504 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 10, riser 2
Location: U1.1-P1-M2.10
4066 0505 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 17, riser 2
Location: U1.1-P1-M2.17
4066 0506 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 18, riser 2
Location: U1.1-P1-M2.18
4066 0507 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 25, riser 2
Location: U1.1-P1-M2.25
4066 0508 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 26, riser 2
Location: U1.1-P1-M2.26
4066 050D Scan interface basic assurance tests
detected memory DIMM group fault
Memory octal A, riser 2
Location: U1.1-P1-M2.1 x8
4066 050E Scan interface basic assurance tests
detected memory DIMM group pair A fault
Memory quad A odd, riser 2
Location: U1.1-P1-M2.1 x4
4066 050F Scan interface basic assurance tests
detected memory DIMM group fault
Memory quad A even, riser 2
Location: U1.1-P1-M2.2 x4
4066 0511 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 3, riser 2
Location: U1.1-P1-M2.3
4066 0512 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 4, riser 2
Location: U1.1-P1-M2.4
212 Service Guide
