Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4066 0534 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 16, riser 2
Location: U1.1-P1-M2.16
4066 0535 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 23, riser 2
Location: U1.1-P1-M2.23
4066 0536 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 24, riser 2
Location: U1.1-P1-M2.24
4066 0537 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 31, riser 2
Location: U1.1-P1-M2.31
4066 0538 Scan interface basic assurance tests
detected memory DIMM fault
Memory DIMM 32, riser 2
Location: U1.1-P1-M2.32
4066 053D Scan interface basic assurance tests
detected memory DIMM group fault
Memory octal D, riser 2
Location: U1.1-P1-M2.7 x8
4066 053E Scan interface basic assurance tests
detected memory DIMM group fault
Memory quad D odd, riser 2
Location: U1.1-P1-M2.7 x4
4066 053F Scan interface basic assurance tests
detected memory DIMM group fault
Memory quad D even, riser 2
Location: U1.1-P1-M2.8 x4
4066 05FF Scan interface basic assurance tests
detected memory on riser fault
Memory failure on riser card 2 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4066 0600 Scan interface basic assurance tests
detected CEC RIO bus adapter
CEC RIO bus adapter
Location: U1.1-P1.1
4066 0601 Scan interface basic assurance tests
detected clock card fault
CEC clock card
Location: U1.1-P1.1.1
4066 3101 Scan interface basic assurance tests
detected RIO port 0 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3102 Scan interface basic assurance tests
detected RIO port 1 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3103 Scan interface basic assurance tests
detected RIO port 2 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3104 Scan interface basic assurance tests
detected RIO port 3 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3121 Scan interface basic assurance tests
detected RIO cable on port 0 fault
1. RIO cable on port 0
Location: U1.1-P1.1/Q1
2. CEC RIO bus adapter
Location: U1.1-P1.1
4066 3122 Scan interface basic assurance tests
detected RIO cable on port 1 fault
1. RIO cable on port 1
Location: U1.1-P1.1/Q2
2. CEC RIO bus adapter
Location: U1.1-P1.1
4066 3123 Scan interface basic assurance tests
detected RIO cable on port 2 fault
1. RIO cable on port 2
Location: U1.1-P1.1/Q3
2. CEC RIO bus adapter
Location: U1.1-P1.1
214 Service Guide
