Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4066 3124 Scan interface basic assurance tests
detected RIO cable on port 3 fault
1. RIO cable on port 3
Location: U1.1-P1.1/Q4
2. CEC RIO bus adapter
Location: U1.1-P1.1
4066 3140 Scan interface basic assurance tests
detected RIO hub 0 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3141 Scan interface basic assurance tests
detected RIO hub 1 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 31FF Scan interface basic assurance tests
detected RIO port fault
CEC RIO bus adapter
Location: U1.1-P1.1
4066 3200 Scan interface basic assurance tests
detected primary I/O drawer fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4066 3201 Scan interface basic assurance tests
detected primary I/O drawer backplane fault
Primary I/O drawer backplane
Location: U0.1-P1
4066 3280 Scan interface basic assurance tests
detected primary RIO adapter fault
Primary RIO adapter
Location: U0.1-P1.1
4066 3281 Scan interface basic assurance tests
detected primary RIO port 0 fault
1. Check RIO cable
Location: U0.1-P1.1/Q1
2. RIO bus adapter
Location: U0.1-P1.1
4066 3282 Scan interface basic assurance tests
detected primary RIO port 1 fault
1. Check RIO cable
Location: U0.1-P1.1/Q2
2. RIO bus adapter
Location: U0.1-P1.1
4066 3283 Scan interface basic assurance tests
detected primary RIO ports fault
RIO bus adapter
Location: U0.1-P1.1
4066 3284 Scan interface basic assurance tests
detected PCI controller PHB0
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4066 3285 Scan interface basic assurance tests
detected PCI controller PHB1 fault
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4066 3286 Scan interface basic assurance tests
detected PCI controller PHB2
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4067 0001 6xx bus processor runtime diagnostics
detected CEC backplane failure
CEC backplane
Location: U1.1-P1
4067 0003 6xx bus processor runtime diagnostics
detected processor fault
All processors
Location: U1.1-P1-C1
4067 0009 6xx bus processor runtime diagnostics
detected memory fault
All memory
Location: U1.1-P1-M1 x2
4067 00A0 6xx bus processor runtime diagnostics
detected CSP service processor firmware
fault
Update system firmware
Location: U0.1-P1/Y1
Chapter 5. Error Code to FRU Index 215
