Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4067 00A1 6xx bus processor runtime diagnostics
detected AIX or system firmware fault
1. Check for AIX updates
2. Check for system firmware updates
Location: U0.1-P1/Y1
4067 00A2 6xx bus processor runtime diagnostics
detected service processor firmware
(processor runtime diagnostics) fault
Check for system firmware updates
Location: U0.1-P1/Y1
4067 00A3 6xx bus processor runtime diagnostics
detected memory plugging fault
All pluggable memory
4067 00A4 6xx bus processor runtime diagnostics
detected application caused fault
Application software
4067 00A5 6xx bus processor runtime diagnostics
detected invalid system configuration
Verify system components are supported and
properly installed.
4067 00A6 6xx bus processor runtime diagnostics
detected no usable memory
1. Ensure that CEC memory is properly
installed.
2. If more than one DIMM is called out, go
to the service processor Memory
Configuration/Deconfiguration Menu to
verify memory DIMMs state. See
″Memory Configuration/Deconfiguration
Menu″ on page 374 for more information.
4067 00A7 6xx bus processor runtime diagnostics
detected hardware problem
Go to “MAP 1540: Minimum Configuration”
on page 110 run CEC minimum configuration
4067 00B0 6xx bus processor runtime diagnostics
detected bus controller lock-unlock failure
RIO bus adapter
Location: U0.1-P1.1
4067 00B1 6xx bus processor runtime diagnostics
detected bus controller failure
RIO bus adapter
Location: U0.1-P1.1
4067 00B3 6xx bus processor runtime diagnostics
detected clock fault
1. Clock card
Location: U1.1-P1.1.1
2. CEC RIO bus adapter
Location: U1.1-P1.1
4067 00B7 6xx bus processor runtime diagnostics
detected insufficient hardware resources to
continue IPL
This error code appears after the initial
testing by the service processor firmware on
the CEC was completed correctly, but a
problem occurred when the firmware tried to
communicate outside the CEC. Suspect a
problem with the RIO interface, either cables
or adapters.
4067 0200 6xx bus processor runtime diagnostics
detected memory riser card fault
Memory riser card 1
Location: U1.1-P1-M1
4067 0201 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 1, riser 1
Location: U1.1-P1-M1.1
4067 0202 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 2, riser 1
Location: U1.1-P1-M1.2
4067 0203 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 9, riser 1
Location: U1.1-P1-M1.9
4067 0204 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 10, riser 1
Location: U1.1-P1-M1.10
4067 0205 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 17, riser 1
Location: U1.1-P1-M1.17
216 Service Guide
