Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4067 0227 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 29, riser 1
Location: U1.1-P1-M1.29
4067 0228 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 30, riser 1
Location: U1.1-P1-M1.30
4067 022D 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory octal C, riser 1
Locations: U1.1-P1-M1.5 x8
4067 022E 6xx bus processor runtime diagnostics
detected memory DIMM group pair A fault
Memory quad C odd, riser 1
Locations: U1.1-P1-M1.5 x4
4067 022F 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad C even, riser 1
Locations: U1.1-P1-M1.6 x4
4067 0231 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 7, riser 1
Location: U1.1-P1-M1.7
4067 0232 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 8, riser 1
Location: U1.1-P1-M1.8
4067 0233 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 15, riser 1
Location: U1.1-P1-M1.15
4067 0234 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 16, riser 1
Location: U1.1-P1-M1.16
4067 0235 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 23, riser 1
Location: U1.1-P1-M1.23
4067 0236 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 24, riser 1
Location: U1.1-P1-M1.24
4067 0237 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 31, riser 1
Location: U1.1-P1-M1.31
4067 0238 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 32, riser 1
Location: U1.1-P1-M1.32
4067 023D 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory octal D, riser 1
Location: U1.1-P1-M1.7 x8
4067 023E 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D odd, riser 1
Location: U1.1-P1-M1.7 x4
4067 023F 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D even, riser 1
Location: U1.1-P1-M1.8 x4
4067 02FF 6xx bus processor runtime diagnostics
detected memory on riser fault
All memory on riser 1
Location: U1.1-P1-M1.1 x32
Memory failure on riser card 1 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4067 0300 6xx bus processor runtime diagnostics
detected processor card fault
Processor card
Location: U1.1-P1-C1
4067 0400 6xx bus processor runtime diagnostics
detected processor card fault
Processor card
Location: U1.1-P1-C2
4067 0500 6xx bus processor runtime diagnostics
detected memory riser card fault
Memory riser card 2
Location: U1.1-P1-M1
4067 0501 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 1, riser 2
Location: U1.1-P1-M2.1
218 Service Guide
