Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4067 0523 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 13, riser 2
Location: U1.1-P1-M2.13
4067 0524 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 14, riser 2
Location: U1.1-P1-M2.14
4067 0525 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 21, riser 2
Location: U1.1-P1-M2.21
4067 0526 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 22, riser 2
Location: U1.1-P1-M2.22
4067 0527 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 29, riser 2
Location: U1.1-P1-M2.29
4067 0528 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 30, riser 2
Location: U1.1-P1-M2.30
4067 052D 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory octal C, riser 2
Location: U1.1-P1-M2.5 x8
4067 052E 6xx bus processor runtime diagnostics
detected memory DIMM group pair A fault
Memory quad C odd, riser 2
Location: U1.1-P1-M2.5 x4
4067 052F 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad C even, riser 2
Location: U1.1-P1-M2.6 x4
4067 0531 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 7, riser 2
Location: U1.1-P1-M2.7
4067 0532 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 8, riser 2
Location: U1.1-P1-M2.8
4067 0533 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 15, riser 2
Location: U1.1-P1-M2.15
4067 0534 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 16, riser 2
Location: U1.1-P1-M2.16
4067 0535 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 23, riser 2
Location: U1.1-P1-M2.23
4067 0536 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 24, riser 2
Location: U1.1-P1-M2.24
4067 0537 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 31, riser 2
Location: U1.1-P1-M2.31
4067 0538 6xx bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 32, riser 2
Location: U1.1-P1-M2.32
4067 053D 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory octal D, riser 2
Location: U1.1-P1-M2.7 x8
4067 053E 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D odd, riser 2
Location: U1.1-P1-M2.7 x4
4067 053F 6xx bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D even, riser 2
Location: U1.1-P1-M2.8 x4
4067 05FF 6xx bus processor runtime diagnostics
detected memory on riser fault
Memory failure on riser card 2 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4067 0600 6xx bus processor runtime diagnostics
detected CEC RIO bus adapter
CEC RIO bus adapter
Location: U1.1-P1.1
