Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4068 3124 Other bus processor runtime diagnostics
detected RIO cable on port 3 fault
1. RIO cable on port 3
Location: U1.1-P1.1/Q4
2. CEC RIO bus adapter
Location: U1.1-P1.1
4068 3140 Other bus processor runtime diagnostics
detected RIO hub 0 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3141 Other bus processor runtime diagnostics
detected RIO hub 1 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 31FF Other bus processor runtime diagnostics
detected RIO port fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3200 Other bus processor runtime diagnostics
detected primary I/O drawer fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4068 3201 Other bus processor runtime diagnostics
detected primary I/O drawer backplane fault
Primary I/O drawer backplane
Location: U0.1-P1
4068 3280 Other bus processor runtime diagnostics
detected primary RIO adapter fault
Primary RIO adapter
Location: U0.1-P1.1
4068 3281 Other bus processor runtime diagnostics
detected primary RIO port 0 fault
1. Check RIO cable
Location: U0.1-P1.1/Q1
2. RIO bus adapter
Location: U0.1-P1.1
4068 3282 Other bus processor runtime diagnostics
detected primary RIO port 1 fault
1. Check RIO cable
Location: U0.1-P1.1/Q2
2. RIO bus adapter
Location: U0.1-P1.1
4068 3283 Other bus processor runtime diagnostics
detected primary RIO ports fault
RIO bus adapter
Location: U0.1-P1.1
4068 3284 Other bus processor runtime diagnostics
detected PCI controller PHB0
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4068 3285 Other bus processor runtime diagnostics
detected PCI controller PHB1
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4068 3286 Other bus processor runtime diagnostics
detected PCI controller PHB2
1. RIO bus adapter
Location: U0.1-P1.1
2. Primary I/O drawer backplane
Location: U0.1-P1
4069 0001 Memory test detected CEC backplane failure CEC backplane
Location: U1.1-P1
4069 0003 Memory test detected processor fault All processors
Location: U1.1-P1-C1
4069 0009 Memory test detected memory fault All memory
Location: U1.1-P1-M1 x2
4069 00A0 Memory test detected CSP service processor
firmware fault
Update system firmware
Location: U0.1-P1/Y1
4069 00A1 Memory test detected AIX or system firmware
fault
1. Check for AIX updates
2. Check for system firmware updates
Location: U0.1-P1/Y1
228 Service Guide
