Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4068 0534 Other bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 16, riser 2
Location: U1.1-P1-M2.16
4068 0535 Other bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 23, riser 2
Location: U1.1-P1-M2.23
4068 0536 Other bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 24, riser 2
Location: U1.1-P1-M2.24
4068 0537 Other bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 31, riser 2
Location: U1.1-P1-M2.31
4068 0538 Other bus processor runtime diagnostics
detected memory DIMM fault
Memory DIMM 32, riser 2
Location: U1.1-P1-M2.32
4068 053D Other bus processor runtime diagnostics
detected memory DIMM group fault
Memory octal D, riser 2
Location: U1.1-P1-M2.7 x8
4068 053E Other bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D odd, riser 2
Location: U1.1-P1-M2.7 x4
4068 053F Other bus processor runtime diagnostics
detected memory DIMM group fault
Memory quad D even, riser 2
Location: U1.1-P1-M2.8 x4
4068 05FF Other bus processor runtime diagnostics
detected memory on riser fault
Memory failure on riser card 2 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4068 0600 Other bus processor runtime diagnostics
detected CEC RIO bus adapter
CEC RIO bus adapter
Location: U1.1-P1.1
4068 0601 Other bus processor runtime diagnostics
detected clock card fault
CEC clock card
Location: U1.1-P1.1.1
4068 3101 Other bus processor runtime diagnostics
detected RIO port 0 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3102 Other bus processor runtime diagnostics
detected RIO port 1 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3103 Other bus processor runtime diagnostics
detected RIO port 2 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3104 Other bus processor runtime diagnostics
detected RIO port 3 fault
CEC RIO bus adapter
Location: U1.1-P1.1
4068 3121 Other bus processor runtime diagnostics
detected RIO cable on port 0 fault
1. RIO cable on port 0
Location: U1.1-P1.1/Q1
2. CEC RIO bus adapter
Location: U1.1-P1.1
4068 3122 Other bus processor runtime diagnostics
detected RIO cable on port 1 fault
1. RIO cable on port 1
Location: U1.1-P1.1/Q2
2. CEC RIO bus adapter
Location: U1.1-P1.1
4068 3123 Other bus processor runtime diagnostics
detected RIO cable on port 2 fault
1. RIO cable on port 2
Location: U1.1-P1.1/Q3
2. CEC RIO bus adapter
Location: U1.1-P1.1
Chapter 5. Error Code to FRU Index 227
