Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4069 022D Memory test detected memory DIMM group
fault
Memory octal C, riser 1
Locations: U1.1-P1-M1.5 x8
4069 022E Memory test detected memory DIMM group
pair A fault
Memory quad C odd, riser 1
Locations: U1.1-P1-M1.5 x4
4069 022F Memory test detected memory DIMM group
fault
Memory quad C even, riser 1
Locations: U1.1-P1-M1.6 x4
4069 0231 Memory test detected memory DIMM fault Memory DIMM 7, riser 1
Location: U1.1-P1-M1.7
4069 0232 Memory test detected memory DIMM fault Memory DIMM 8, riser 1
Location: U1.1-P1-M1.8
4069 0233 Memory test detected memory DIMM fault Memory DIMM 15, riser 1
Location: U1.1-P1-M1.15
4069 0234 Memory test detected memory DIMM fault Memory DIMM 16, riser 1
Location: U1.1-P1-M1.16
4069 0235 Memory test detected memory DIMM fault Memory DIMM 23, riser 1
Location: U1.1-P1-M1.23
4069 0236 Memory test detected memory DIMM fault Memory DIMM 24, riser 1
Location: U1.1-P1-M1.24
4069 0237 Memory test detected memory DIMM fault Memory DIMM 31, riser 1
Location: U1.1-P1-M1.31
4069 0238 Memory test detected memory DIMM fault Memory DIMM 32, riser 1
Location: U1.1-P1-M1.32
4069 023D Memory test detected memory DIMM group
fault
Memory octal D, riser 1
Location: U1.1-P1-M1.7 x8
4069 023E Memory test detected memory DIMM group
fault
Memory quad D odd, riser 1
Location: U1.1-P1-M1.7 x4
4069 023F Memory test detected memory DIMM group
fault
Memory quad D even, riser 1
Location: U1.1-P1-M1.8 x4
4069 02FF Memory test detected memory on riser fault All memory on riser 1
Location: U1.1-P1-M1.1 x32
Memory failure on riser card 1 that cannot be
automatically isolated. go to “MAP 1540:
Minimum Configuration” on page 110 and run
CEC drawer minimum configuration for
further isolation.
4069 0300 Memory test detected processor card fault Processor card
Location: U1.1-P1-C1
4069 0400 Memory test detected processor card fault Processor card
Location: U1.1-P1-C2
4069 0500 Memory test detected memory riser card fault Memory riser card 2
Location: U1.1-P1-M1
4069 0501 Memory test detected memory DIMM fault Memory DIMM 1, riser 2
Location: U1.1-P1-M2.1
4069 0502 Memory test detected memory DIMM fault Memory DIMM 2, riser 2
Location: U1.1-P1-M2.2
4069 0503 Memory test detected memory DIMM fault Memory DIMM 9, riser 2
Location: U1.1-P1-M2.9
Chapter 5. Error Code to FRU Index 231
