Table 7. Service Processor Error Codes (continued)

Error Code Description Action/

Possible Failing FRU

4B2F 515B Processor system and error code detected

1100W ac power supply fault

1100W ac power supply

Locations: U1.1-V1

U1.1-V2

4B2F 51AC Processor system and error code detected

595W ac power supply fault

595W ac power supply

Locations: U0.1-V1

U0.1-V2

4B2F 51AD Processor system and error code detected

595W dc power supply fault

595W dc power supply

Locations: U0.1-V1

U0.1-V2

4B2F 51AE Processor system and error code detected

1100W dc power supply fault

1100W dc power supply

Locations: U1.1-V1

U1.1-V2

336 Service Guide
