Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4B2F 271A Processor system and error code detected
primary I/O planar fault
Primary I/O planar
Location: U0.1-P1
4B2F 271D Processor system and error code detected
secondary I/O planar fault
Secondary I/O planar
Locations: U0.2-P1
U0.3-P1
U0.4-P1
4B2F 2733 Processor system and error code detected
I/O clock fault
CEC RIO bus adapter
Location: U1.1-P1.1
4B2F 27AA Processor system and error code detected a
2W/4W regulator fault
2W/4W regulator card
Location: U1.1-P1-V1
4B2F 27AB Processor system and error code detected an
8W regulator fault
8W regulator card
Location: U1.1-P1-V1
4B2F 281C Processor system and error code detected
CEC backplane fault
CEC backplane
Location: U1.1-P1
4B2F 281D Processor system and error code detected
Model 6M1 CEC backplane fault
CEC backplane
Location: U1.1-P1
4B2F 285D Processor system and error code detected
SPCN fan controller fault
1. SPCN fan controller
Location: U0.1-X2
2. I/O drawer power distribution board
Location: U0.1-X1
4B2F 288A Processor system and error code detected
memory riser card fault
1. Go to the service processor Memory
Configuration/Deconfiguration Menu to
verify memory DIMMs state. See
″Memory Configuration/Deconfiguration
Menu″ on page 374 for more information.
2. Memory riser card
Locations: U1.1-P1-M1
U1.1-P1-M2
4B2F 300A Processor system and error code detected 32
MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 300B Processor system and error code detected
128 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 300C Processor system and error code detected
256 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 300D Processor system and error code detected
512 MB (stacked) DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 300E Processor system and error code detected
512 MB (unstacked) DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 301F Processor system and error code detected
128 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2F 303A Processor system and error code detected 1
GB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
Chapter 5. Error Code to FRU Index 335
